Canyon Strive CFR Underdog Mountain Bikes
Frame
-
Frame
- Canyon Strive CFR
- The Strive CFR chassis has carried the Canyon Enduro World Series team to two fastest-team titles. Light (just 2,400 grams), burly, and remarkably versatile, the Strive CFR is one bike that does it all.
- Axle dimension: 12×148 mm
- Material: Carbon (CF)
-
Rear Shock
- FOX FLOAT X2 Performance
- Gravity ready, with super smooth performance and sensivity through the gnarliest terrain.
-
Suspension Fork
- FOX 38 Performance Elite
- Axle dimension: 15×110 mm
- Stanchion Diameter: 38 mm
- Travel: 170 mm
- Fork steer tube diameter: 1 1/8″ – 1,5″
- Offset: 44 mm
Drivetrain
-
Rear Derailleur
- Shimano Deore XT M8100 12speed
- Precise 1×12 drivetrain.
-
Chainguard
- e*thirteen Ultra Compact Upper Slider
-
Shift Lever
- Shimano Deore XT, 12-speed
- Rear derailleur shifter, 12-speed, Textured rubber lever pad, Multi-Release, 2-way release, I-Spec EV clamp allows 14mm lateral adjustment and 20-degrees rotation adjustment, 130 g
-
Cassette
- Shimano XT, 12-speed (10-51)
- Cassette size: 10-51T
- Gear range: 510%
-
Crank
- Shimano XT M8120 32T
- Number of chainrings: 1
-
Bottom bracket
- Shimano MT800, Threaded
- Hassle-free Shimano Hollowtech II threaded bottom bracket
-
Chain
- Shimano M7100 12-speed
Brakes
-
Disc Brake
- Shimano Deore XT M8120
-
Disc Brake
- Shimano Deore XT M8120
- High-power 4-piston brake, reach adjust, quick pad retraction, banjo-type connection, ICE TECH brake pads, 410 g
-
Brake Rotor
- Shimano RT86, 203mm
- A big (203mm) Shimano RT86 brake rotor delivers equally big stopping power.
Wheels
-
Wheel
- DT Swiss EX511 370LN
- Rotor mount: IS 6-bolt
-
Wheel
- DT Swiss EX511 370LN
- Rotor mount: IS 6-bolt
-
Tyre
- Maxxis Minion DHRII 3C MaxxTerra EXO+ 2,4×29
- Width: 2,4″
-
Tyre
- MAXXIS ASSEGAI 3C MaxxGrip
- Width: 2,5″
-
Thru Axle
- Canyon Quixle Thru Axle
- The Canyon Quixle combines the stiffness of a through axle with the ease-of-use of a quick-release. You can quickly remove the rear wheel without tools. The handle discreetly slides into the axle after usage. The Quixle is only combined with the rear wheel.
Cockpit
-
Stem
- Canyon G5 Stem
- Modern design, extreme durability: Canyon G5 components were developed by our pros on the world’s toughest trails.
- Clamping Diameter: 31,8 mm
-
Handlebar
- Canyon G5 Riser Bar
- G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability.
- Clamping Diameter: 31,8 mm
- Width: 780 mm
- Rise: 30 mm
-
Grips
- Canyon G5 Grips
- Get huge grip, with or without gloves. The clamp guarantees a tight lock on the bar.
Seat
-
Saddle
- Ergon SM10 Enduro Comp
-
Seatpost
- G5 Adjustable Dropper Post
- Clamp diameter: 30,9 mm
Accessories
-
Pedals
- None included
-
Manuals and Accessories
- Canyon Bag
- Storage box for tools and replacement parts.
-
Manuals and Accessories
- Canyon Smallbox
- Content: Manual, Torque Wrench incl. Bit Set, Shock Pump, Assembly Paste
-
Manuals and Accessories
- Strive Quick Start Guide
