Trek Supercaliber 9.7 Bike
With Supercaliber 9.7 you no longer have to choose between hardtail and full-suspension on race day. Every element of this bike is developed for fast capability, from the efficient IsoStrut shock to weight-saving pivotless seat stays that cut down on trail chatter. A lightweight parts spec completes this XC-crushing machine.
Specifications
*spec applies to all sizes unless otherwise noted
Frameset
| Frame | OCLV Mountain Carbon main frame & stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel |
|---|---|
| Fork | RockShox Reba RL, Solo Air spring, Motion Control damper, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 100mm travel |
| Shock | Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position damper, 235×32.5mm |
| Max compatible fork travel | 120mm |
Wheels
| Wheel front | Bontrager Kovee Elite 23 carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
|---|---|
| Wheel rear | Bontrager Kovee Elite 23 carbon, Tubeless Ready, centerlock, Shimano 8/9/10 freehub, Boost148, 12mm thru axle |
| Tire | Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29×2.20” |
| *Tire part | Size: S, M, M/L, L, XL Bontrager TLR sealant, 6oz |
| Size: S, M, M/L, L, XL Bontrager TLR valve, 50mm |
|
| Size: S, M, M/L, L, XL Bontrager TLR sealant |
|
| Max tire size | 29×2.40″ |
Drivetrain
| Shifter | SRAM NX Eagle, 12 speed |
|---|---|
| Rear derailleur | SRAM NX Eagle |
| *Crank | Size: S SRAM NX Eagle, DUB, 32T alloy ring, Boost (52mm chainline), 170mm length |
| Size: M, M/L, L, XL SRAM NX Eagle, DUB, 32T alloy ring, Boost (52mm chainline), 175mm length |
|
| Bottom bracket | SRAM DUB, 92mm, PressFit |
| Cassette | SRAM PG-1230 Eagle, 11-50, 12 speed |
| Chain | SRAM NX Eagle, 12 speed |
| Max chainring size | 36T |
Components
| Saddle | Bontrager Montrose Comp, steel rails, 138mm width |
|---|---|
| *Seatpost | Size: S Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 330mm length |
| Size: M, M/L, L, XL Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 400mm length |
|
| Handlebar | Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width |
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| *Stem | Size: S Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 60mm length |
| Size: M, M/L Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 70mm length |
|
| Size: L, XL Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 80mm length |
|
| *Headset | Size: S, M, M/L, L, XL Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8” top, 1.5” bottom |
| Size: S, M, M/L, L, XL Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8” top, 1.5” bottom |
|
| Brake | Shimano hydraulic disc, MT501 lever, MT500 caliper |
| *Brake rotor | Size: S, M, M/L, L, XL Shimano RT56, 6-bolt, 180mm |
| Size: S, M, M/L, L, XL Shimano RT56, 6-bolt, 160mm |
Weight
| Weight | M – 11.51 kg / 25.38 lbs (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
Sizing & fit
The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit. That’s why you’ll see some overlap in our recommendations. Not every rider who’s 5´8˝, for example, will fit on the same size bike. The best way to find your perfect fit is to consult the experts at your local retailer.
Rider Height
Inseam
S
153.0 – 166.5 cm
5’0.2″ – 5’5.6″
72.0 – 79.0 cm
28.3″ – 31.1″
M
161.0 – 172.0 cm
5’3.4″ – 5’7.7″
76.0 – 81.0 cm
29.9″ – 31.9″
M/L
165.5 – 179.0 cm
5’5.2″ – 5’10.5″
77.0 – 84.0 cm
30.3″ – 33.1″
L
177.0 – 188.0 cm
5’9.7″ – 6’2.0″
83.0 – 88.0 cm
32.7″ – 34.6″
XL
186.0 – 196.0 cm
6’1.2″ – 6’5.2″
87.0 – 92.0 cm
34.3″ – 36.2″
2XL
195.0 – 203.0 cm
6’4.8″ – 6’7.9″
92.0 – 95.0 cm
36.2″ – 37.4″
All measurements provided in cm unless otherwise noted.
| Frame size number | Frame size letter | Wheel size | A — Seat tube | B — Seat tube angle | Effective seat tube angle | C — Head tube length | D — Head angle | E — Effective top tube | F — Bottom bracket height | G — Bottom bracket drop | H — Chainstay length | I — Offset | J — Trail | K — Wheelbase | L — Standover | M — Frame reach | N — Frame stack |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15.5 | S | 29″ | 39.4 | 70.0° | 74.0° | 9.0 | 69.0° | 56.5 | 32.0 | 5.3 | 43.0 | 4.4 | 9.6 | 107.9 | 75.0 | 39.5 | 59.4 |
| 17.5 | M | 29″ | 41.9 | 70.5° | 74.0° | 9.0 | 69.0° | 59.5 | 32.0 | 5.3 | 43.0 | 4.4 | 9.6 | 110.6 | 76.0 | 42.5 | 59.4 |
| 18.5 | ML | 29″ | 44.5 | 70.5° | 74.0° | 9.0 | 69.0° | 61.0 | 32.0 | 5.3 | 43.0 | 4.4 | 9.6 | 112.1 | 76.0 | 44.0 | 59.4 |
| 19.5 | L | 29″ | 47.0 | 71.0° | 74.0° | 9.0 | 69.0° | 62.5 | 32.0 | 5.3 | 43.0 | 4.4 | 9.6 | 113.6 | 78.7 | 45.5 | 59.4 |
| 21.5 | XL | 29″ | 50.8 | 71.0° | 74.0° | 10.5 | 69.0° | 65.9 | 32.0 | 5.3 | 43.0 | 4.4 | 9.6 | 117.2 | 78.7 | 48.5 | 60.8 |
| 23.0 | XXL | 29″ | 54.6 | 71.0° | 74.0° | 12 | 69.0° | 68.3 | 32 | 5.3 | 43 | 4.4 | 9.6 | 119.7 | 78.7 | 50.5 | 62.2 |
